Architectural BIM Case study – BIM Content Creation

The scope of work was parametric family creation, with 14 types of partition families having varying degrees of complexity, from simple to knotty parameters and nested generic models. Inputs from the client included detailed specification set in CAD and pdf formats and also iges files for modeling the irregular shapes. These partition families contained odd shaped panels fulfilling the aesthetic purpose and a number of hardware like cables, supports, frames etc. to support the panels. The customer required a high degree of customization in addition to the option to add panels to the single panel as an instance parameter. Also, they needed these families to be hosted on any raised surface and the option to choose panel finish. Advenser delivered Revit model for commercial purpose.
