POINT CLOUD SCAN TO BIM MODELLING SERVICES

POINT CLOUD TO BIM SERVICES



As a scan to BIM service provider with 12+ years of experience, Advenser caters to the needs of architects, general contractors, mechanical/plumbing/HVAC contractors and civil contractors in the construction industry. The intelligent as-built model created will contain all the building data embedded in it which includes but not limited to beams, columns, ceilings, roofs, walls, ducts and pipes. This facilitates our clients to analyze the existing condition of a building for renovation or demolition purposes.

Point cloud modeling services

Point cloud is a set of data points in a 3D coordinate system representing the external surface of an object or building including its geometry and color. 3D scanners are used to measure Point cloud data as a set of vector points, which are then converted to accurate parametric REVIT models. Once imported into Revit, we can trace around the point data with our Revit families quickly building up a 3D model with the point cloud as a reference. The 3D scanned data captures every single detail, thus eliminating the need for repeated site visits.

Once the point cloud data is received, we export them on to a CAD or BIM platform to create an accurate As-Built Building Information Model depicting the pipes, walls, slabs, roof planes, terrain and vegetation in and around the building.

Once the 3D point cloud data is segregated and exported to a BIM package, conventional deliverables like 2D plans, elevations, and sections can be easily extracted.

Our team possesses resources with adequate skillset and experience in this procedure. We utilize the Revit Families furnished by the clients and adapt to the specific standards used by them.

Inputs expected from Client side:

Laser scanned data of the building or structure

Site photographs and photosphere of the structure

Final model and design drawings (if available)

Deliverables from Scan to BIM:

3D Model creation at LOD 500

As-Built Drawings & documentations

As-Built elevation & plan view drawings

Point cloud conversion
Point cloud conversion
Request for more Point cloud Samples

    Get a quote for your Point cloud project

      (Compatible file types- pdf, dwg of size below 20 MB)
      For file size greater than 20 MB, use a third party service (Dropbox, Wetransfer or Yousendit) or contact us for FTP.

      Point Cloud to Mesh Services

      Advenser provides point cloud to mesh services to a wide range of AEC industry sectors which includes but not limited to architects, general contractors, civil contractors, and mechanical/ plumbing/ HVAC contractors.  When a point cloud scan is provided to us which was typically captured using a 3D laser scanner, comprising of a set of million data points, representing the 3D coordinates of the external surfaces of the structure or the building, our engineers make use of latest reconstruction methods to create a mesh from the provided point cloud.

      As per the client’s requirement, we provide point cloud to mesh, as-built or 3D solids engineering models.

      Point Cloud to Mesh Services

      Types of Projects that benefit from Scan to BIM

      Renovation activities

      Building extension & modifications

      Facility management procedures

      Building maintenance & surveillance

      Refurbishment

      Retrofit purposes

      Building demolition tasks

      Point cloud takeoff
      Rear side site view
      Point cloud model of rear side site

      We Follow the Following International Standards

      We understand that no two clients are going to have the same requirements, which is why our team of engineers are groomed to be a flexible workforce. When you hire Advenser to work on your projects we work as an extension of your team working to achieve a common goal. Our association with a global clientele makes us proficient in the following international BIM modeling standards

      ANSI - American National Standards Institute
      ASME- American Society of Mechanical Engineers
      ISO- International standards organization
      GOST – Russian standards
      BSI - British Standards Institution
      DIN - Deutsches Institut für Normung (German standards)
      BNQ- Bureau de normalization du Quebec
      GB – Guobiao Standards (Chinese standards)
      ISO standards- International Organization for Standardization

      Our Quality Assurance:

      The team of engineers and BIM modelers at Advenser are highly motivated and quality driven striving to offer our clients services of impeccable quality. We have a dedicated team of quality analysts responsible for closely monitoring the models as it progresses through each level. Every model is carefully examined to ensure that

      Strict adherence to the international industry/building codes are made
      Errors if any, are not left unnoticed
      Project design targets and goals are met
